In this paper a novel type of piezoelectric microelectromechanical loudspeaker is presented. The device concept is based on concentrically cascaded lead zirconate titanate actuators making it the first integrated two-way MEMS speaker reported. As a further novelty, the device is designed to operate without a closed membrane significantly improving the acoustic performance, energy efficiency, and manufacturability. Extensive finite element analysis studies have revealed a very high SPL of more than 79 dB in 10 cm distance at 500 Hz for a device 1 cm² in size operated at 30 V. At higher frequencies even larger SPL values are calculated enabling a flat frequency response with 89 dB for frequencies above 800 Hz. Based on this concept first speaker prototypes have been fabricated using MEMS technology.
Author (s): Stoppel, Fabian; Niekiel, Florian; Giese, Thorsten; Gu-Stoppel, Shanshan; Männchen, Andreas; Nowak, Johannes; Beer, Daniel; Wagner, Bernhard
Affiliation:
Fraunhofer Institute for Silicon Technology ISIT, Itzehoe, Germany; Fraunhofer Institute for Digital Media Technology IDMT, Ilmenau, Germany
(See document for exact affiliation information.)
AES Convention: 143
Paper Number:9874
Publication Date:
2017-10-06
Import into BibTeX
Session subject:
Transducers
Permalink: https://aes2.org/publications/elibrary-page/?id=19271
(796KB)
Click to purchase paper as a non-member or login as an AES member. If your company or school subscribes to the E-Library then switch to the institutional version. If you are not an AES member Join the AES. If you need to check your member status, login to the Member Portal.
Stoppel, Fabian; Niekiel, Florian; Giese, Thorsten; Gu-Stoppel, Shanshan; Männchen, Andreas; Nowak, Johannes; Beer, Daniel; Wagner, Bernhard; 2017; Novel Type of MEMS Loudspeaker Featuring Membrane-Less Two-Way Sound Generation [PDF]; Fraunhofer Institute for Silicon Technology ISIT, Itzehoe, Germany; Fraunhofer Institute for Digital Media Technology IDMT, Ilmenau, Germany; Paper 9874; Available from: https://aes2.org/publications/elibrary-page/?id=19271
Stoppel, Fabian; Niekiel, Florian; Giese, Thorsten; Gu-Stoppel, Shanshan; Männchen, Andreas; Nowak, Johannes; Beer, Daniel; Wagner, Bernhard; Novel Type of MEMS Loudspeaker Featuring Membrane-Less Two-Way Sound Generation [PDF]; Fraunhofer Institute for Silicon Technology ISIT, Itzehoe, Germany; Fraunhofer Institute for Digital Media Technology IDMT, Ilmenau, Germany; Paper 9874; 2017 Available: https://aes2.org/publications/elibrary-page/?id=19271
