Squared Butterworth crossovers, also known as Linkwitz-Riley crossovers, have found extensive use in audio ap-plications for splitting a spectrum into multiple segments. However, for applications involving low-pass and high-pass filters, alternative options like Chebyshev (Type-I and II) and elliptic filters often offer advantages. Squared Chebyshev and elliptic crossovers have garnered less attention, primarily due to the absence of closed-form ex-pressions, owing to their mathematical complexity. This paper introduces closed-form expressions, accompanied by explicit constraints for achieving perfect magnitude reconstruction in these crossovers. Furthermore, as these crossovers are all-pass equivalent, they can serve as fundamental components for constructing more intricate filter structures, including shelving, parametric, and notch filters based on Chebyshev and elliptic designs.
(See document for exact affiliation information.)
